Glass Greenhouse

Glass greenhouse has the characteristic of beautiful appearance,good light transmission,good display effect,long service life and so on.automatic control equipment,heating system,shading screen system,fog or water curtain cooling system,CO2 system,light system and spray and drip irrigation and fertilizer system,computer control system,roof sprinkler system

Send Inquiry

Description

Technical Parameters

Glass Greenhouse

Glass greenhouse refers to a greenhouse that uses glass as a lighting material, which belongs to a kind of greenhouse. In cultivation facilities, glass greenhouse is a form with the longest service life and is suitable for use in various regions and various climatic conditions. The industry is divided into different construction models according to the size of the span and bay, and is divided into different types of use: vegetable glass greenhouses, flower glass greenhouses, nursery glass greenhouses, ecological glass greenhouses, scientific research glass greenhouses, three-dimensional glass greenhouses, special-shaped glass greenhouses Glass greenhouses, leisure glass greenhouses, smart glass greenhouses, etc. The area and use method can be freely adjusted by the greenhouse owner. The smallest is a courtyard leisure type. The largest height can reach more than 10 meters, the span can reach 16 meters, and the maximum bay can reach 10 meters. The degree of intelligence can reach one-key control. The winter heating problem of glass greenhouses can adopt a variety of heating methods, and the energy consumption cost is in the middle, which is mostly acceptable

Natural ventilation The glass greenhouse relies on natural ventilation to adjust the indoor environment most of the time. The structural form of large-scale productive glass greenhouses is generally a double-slope multi-span greenhouse, and the ventilation form is to set ventilation windows on the side walls and roof ridges. The total ventilation area is not less than 15% of the greenhouse area, preferably more than 30%. When the ridge window is opened, the sash should preferably be inclined upwards beyond the horizontal plane. When fully opened, it forms an angle of 100 with the horizontal plane to obtain a good ventilation effect. The ventilation volume of natural ventilation is related to the wind speed, wind direction, the position of the ventilation window, the area of the ventilation window and the temperature difference between inside and outside the greenhouse. When the total area of ventilation windows is 27% of the indoor floor area, if only the ridge is ventilated, even if the outdoor wind speed reaches 10 km/h, the ideal air change rate of 0.75 times per minute cannot be achieved; When the ventilation window is fully opened, the ventilation rate can reach 0.68 times/min in almost no wind, which is close to the normal recommended ventilation rate of 0.75 times/min.
2. Although forced ventilation glass greenhouses rely on natural ventilation to adjust the environment most of the time, when the temperature in summer is high, especially in hot weather when the outdoor temperature exceeds 33 °C, it is difficult to meet the greenhouse cooling requirements by natural ventilation alone. Forced ventilation is used. Cooling down with other measures is a commonly used method in production. Forced ventilation is the use of fans to convert electrical energy or other mechanical energy into wind energy, forcing air flow to conduct greenhouse ventilation and achieve cooling effect. The theoretical cooling limit of forced ventilation is that the indoor air temperature is equal to the outdoor air temperature. Because, at this time, the temperature difference between inside and outside of the greenhouse is zero, and the ventilation rate is infinite, which is impossible in practical application. Due to mechanical equipment and plant physiological reasons, the ventilation intensity of the general greenhouse is 0.75 to 1.5 times per minute. 5 times, the temperature difference between inside and outside of the greenhouse can be controlled within 5℃
